Simple to operate with a rapid response time. The BA630 has an automatic test-setting function enabling easy recall for frequent testing of the same items without additional user programming. USB and RS-232 interfaces provide computer and printer connections to store test programs and results. No additional software is needed to take readings, giving users total freedom to collect data on a production floor or in the field. A single 400-watt halogen bulb heats samples in 1 °C selectable increments. Three heating options give users the flexibility to customise test methods and temperatures for different materials.
Hardware
- Scratch-resistant aluminium housing protects internal components
- Colour-coded keys facilitate quick recognition of the most frequently used buttons
- Pan lifter allows easy placement and removal of samples
- RS-232 interface is available to provide speedy connection to computers and printers
- USB host for memory card and USB I/O interface
- USB interface included for data communication
- Temperature range 50°C to 160°C in one-degree increments
Software
- Three settings for heating sample include ramp-up, stepped temperatures and single temperature
- Seven preset drying modes allow test routines for several products
- Audible overload alarm warns when capacity is exceeded
- Testing can be set to start automatically when lid closes
- Calibration for temperature and weight
- Multilingual display allows use in many different countries
- Quick and easy configuration using the keypad
- Zero-tracking feature ensures display returns to zero reading
- Internal memory stores 49 different receipes and up to 99 test results,and additional test results and settings can be stored on a flash drive
Display
- Vivid, backlit LCD easily visible in any lighting conditions
- Programmable backlight can be set to "always on," "always off" or "light only when weighing"
- Capacity tracker built into display for easily monitoring possible overloads
Power
Specification
| Capacity |
50g |
| Readability |
0.001g/0.01% |
| Repeatability |
0.001g |
| Weighing Units |
g, %M, %S, ATRO %M, ATRO %S |
| Calibration |
External calibration |
| Stabilization Time |
3.0 |
| Pan Size |
100mm diameter |
| Linearity |
0.002g |
| Power Supply |
Mains power cord |
| Construction |
Die-cast aluminium |
| Interface |
RS-232, USB |
| Operating Temperature |
0° to 40°C |
| Net Weight |
6kg |
| Overall Dimensions |
250 x 360 x 185mm (wxdxh) |
| Approvals |
N/A |
| Display Digit Height |
24mm |
| Heating Technology |
Einzelner 400W Halogenlampe |
| Memory Settings |
Internal memory stores up to 99 test results and 49 programmable user settings External USB drive for limitless data storage of test results and settings |
