Moisture and Damp Meter with replaceable pins

Moisture and Damp Meter with replaceable pins

Moisture and Damp Meter with replaceable pins
for timber & building materials
CodeTH181
Tariff902480 90
Click to save page as PDFSave Page to PDF
or
Call Impact +44 (0)1294 602626

Compact, general purpose moisture meter designed for building professionals to check the moisture content in a variety of construction materials.
  • easy-to-read, digital display with 20-LED bar graph
  • specifically designed for the building professional
  • five scales - concrete, plaster, two timber & reference
  • 2 year guarantee
The TH181 moisture meter features a 20-LED bar graph within the keypad which displays current moisture levels; green for 'OK', amber for 'WARNING' or red for 'DAMP'. It incorporates a large, easy to read, LCD display with low battery indication. The general purpose moisture meter incorporates five scales.
  1. Wood 1 (W1) 6.0 to 40.0 %
  2. Wood 2 (W2) 8.0 to 40.0 %
  3. Plaster (P1) 0.1 to 15.0 %
  4. Concrete (C1) 0.5 to 12.0 %
  5. Linear or Reference (Lin) 0 to 1000
The meter is housed in a robust ABS case and is powered by three AAA batteries that give a minimum of 350 hours battery life. The instrument will power off automatically after ten minutes, maximising battery life. This feature can be disabled by the user, if required.

Each moisture meter incorporates two 1.2mm diameter x 7mm long pointed, replaceable pins and is supplied in a zip wallet complete with 50 spare pins.


Specification
scale 1 Wood 1 (W1): 6.0 to 40.0 %
scale 2 Wood 2 (W2): 8.0 to 40.0 %
scale 3 Plaster (P1): 0.1 to 15.0 %
scale 4 Concrete (C1): 0.5 to 12.0 %
scale 5

Linear or Reference (Lin): 0 to 1000

resolution 0.1% or 1 (linear scale)
accuracy ±1% moisture content
battery 3 x 1.5 volt AAA
battery Life 350 hours
display 12mm LCD
dimensions 25 x 56 x 128mm
weight 130g
case material ABS plastic with Biomaster anti-bacterial additive
country of manufacture UK
measurement scale % moisture & linear
